Features and Specifications of the Wayne Kerr 65120B Precision Impedance Analyzer include:

• Precise high frequency impedance measurements
• Characterize components from 20 Hz to 120 MHz
• Comprehensive measurement functions
• Easy to use with large TFT touch screen
• Clear graphic displays aids measurements
• Traditional LCR Meter mode for single and repetitive measurements
• Protection against charged capacitors
• Resonance Search
• Equivalent Circuit Analysis Function
• Fully programmable over GPIB
• Intuitive user interface
• Keyboard and mouse optional control
• AC Measurement Parmeters / Functions:
  • Impedance (Z)
  • Phase Angle (Ø)
  • Capacitance (C)
  • Dissipation Factor (D)
  • Inductance (L)
  • Quality Factor (Q)
  • Resistance (R)
  • Reactance (X)
  • Conductance (G)
  • Susceptance (B)
  • Admittance (Y)
• High Measurement Accuracy:
  • Basic measurement accuracy:  05%
  • Capacitance, Inductance and Impedance basic accuracy:  +0.05%
  • Dissipation Accuracy:  +0.0005
  • Quality Factor Accuracy:  +0.05%
• Variable drive and bias levels:
  • AC drive level:  10m V to Vrms (varies with frequency)
  • 200μA to 20mArms (varies with frequency)
  • Signal source impedance: 5 ohm nominal
• Data storage and retrieval:  all measurement and setup data can be stored using Ethernet interface or a USB flash memory (supplied as standard)
• Display format: Series or parallel equivalent circuit - all parameters
• Frequency:  20 Hz to 120 MHz
• Mode of operation:
  • Graphical sweep mode:
    • Allows graphical sweep of any two measurement parameters
    • Swept parameters: frequency, drive level or DC bias
  • Meter mode:  Allows the instrument to be used as a standard LCR meter
  • Setup Data:  Up to 20 instrument setups may be locally stored for each mode
  • Equivalent Circuit Analysis
• Measurement Connections:  4 front panel BNC connectors permit 3 or 4 terminal connections with the screens at ground potential
